Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Current Rating
- 20A
- Illumination
- Non-Illuminated
- Uzunluk
- 28.6mm
- Yayın Yılı
- 2001
- Pozisyon Sayısı
- 3
- Ratings
- Dust Tight, IP67, Waterproof
- Panel Cutout Dimensions
- Circular - 12.40mm Dia
- Reach Svhc
- Unknown
- Terminal Stili
- Screw Terminal
- Özellikler
- Sealed
- Montaj Tipi
- Panel Mount
- Sealing
- DUST PROOF; WATER PROOF
- Voltage Rated Dc
- 250V
- Actuator Type
- Standard Round
- Switch Function
- On-Off-On
- Seri
- NT
- Ambalaj
- Bulk
- Fabrika Tedarik Süresi
- 11 Weeks
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 15.7mm
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 250V
- Switch Type
- TOGGLE SWITCH
- Contact Dc Max Rating R Load
- 20A@28VDC
- Kurşunsuz Kodu
- yes
- Montaj
- Bushing
- Current Rating Amps
- 15A AC
- Actuator Length
- 17.02mm
- Bushing Thread
- 15/32-32
- Ingress Protection
- IP67/68 - Dust Tight, Waterproof
- Contact Ac Max Power Rating R Load
- 1HP@250VAC
- Illumination Type
- Illuminated, Non-Illuminated
- Akım Değeri
- 15A
- Body Height
- 29.46mm
- Orientation
- Straight
- Max Current Rating
- 20A
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 277V
- Contact Ac Max Rating R Load
- 15A@277VAC
