Specifications
- Max Voltage Rating Ac
- 125V
- Number Of Ports
- 1
- Ul Flammability Code
- 94V-0
- Mil Conformance
- NO
- Contact Style
- TELCOM, MODULAR
- Shielding
- Unshielded
- Mixed Contacts
- NO
- Housing Material
- Polycarbonate (PC)
- Contact Finish
- Gold
- Empty Shell
- NO
- Option
- GENERAL PURPOSE
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Terminal
- IDC
- JESD-609 Kodu
- e3
- Wirecable Gauge
- 24 AWG
- Total Number Of Contacts
- 8
- Iec Conformance
- NO
- Orientation
- Straight
- Number Of Positionscontacts
- 8p8c (RJ45, Ethernet)
- ECCN Kodu
- EAR99
- Uzunluk
- 0.984 24.99mm
- Maks. Çalışma Sıcaklığı
- 60°C
- Cable Types
- Round Cable, Not Specified
- Seri
- TM23
- Reference Standard
- UL
- Wirecable Type
- Round
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Parça Durumu
- Active
- Rated Current Signal
- 1A
- Max Current Rating
- 1A
- Kurşunsuz
- Lead Free
- Contact Materials
- Phosphor Bronze
- Gender
- Male
- Reliability
- COMMERCIAL
- Filter Feature
- NO
- Wire Gauge
- 24 AWG
- Min. Çalışma Sıcaklığı
- -25°C
- Renk
- Translucent - Clear
- Yayın Yılı
- 2006
