Specifications
- Housing Color
- Black
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL
- Mixed Contacts
- NO
- Stack Height
- 3.5mm
- Insulation Height
- 0.197 5.00mm
- JESD-609 Kodu
- e3
- Contact Materials
- Phosphor Bronze
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Polyamide
- Çalışma Sıcaklığı
- -35°C~85°C
- Number Of Positions Loaded
- All
- Fabrika Tedarik Süresi
- 10 Weeks
- Mil Conformance
- NO
- Contact Resistance
- 30mOhm
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Insulation Resistance
- 1GOhm
- Iec Conformance
- NO
- Pitch Mating
- 0.100 2.54mm
- Kurşunsuz Kodu
- yes
- Fastening Type
- Push-Pull
- Rated Current Signal
- 3A
- Contact Length Post
- 0.118 3.00mm
- Pcb Contact Pattern
- RECTANGULAR
- Flammability Rating
- UL94 V-0
- Style
- Board to Board
- Material Flammability Rating
- UL94 V-0
- Akım Değeri
- 3A
- Nominal Gerilim
- 250VAC
- Gender
- Female
- Option
- GENERAL PURPOSE
- Contact Finish Mating
- Tin
- RoHS Durumu
- RoHS Compliant
- Kurşunsuz
- Lead Free
- Parça Durumu
- Active
- Seri
- MDF7
- Terminal
- Solder
- Ambalaj
- Bulk
- Contact Finish Thickness Post
- 78.7μin 2.00μm
