HIF3FB-16DA-2.54DSA(71)

Specifications

Ul Flammability Code

94V-0

Durability

500 Cycles

Insulation Materials

Polybutylene Terephthalate (PBT)

Mixed Contacts

NO

Dielectric Withstanding Voltage

650VAC V

Contact Type

Female Socket

ECCN Kodu

EAR99

Material Flammability Rating

UL94 V-0

Terminal

Solder

Number Of Positions Loaded

All

Mating Contact Pitch

0.1 inch

Fastening Type

Push-Pull

Polarization Key

POLARIZED HOUSING

Din Conformance

NO

Stack Height Mating

12.2mm

Ambalaj

Tray

Additional Feature

LOW PROFILE

Contact Finish Thickness Mating

8.00μin 0.203μm

RoHS Durumu

RoHS Compliant

Parça Durumu

Active

Özellikler

Polarizing Key

Length Termination

0.098 inch

Filter Feature

NO

Reliability

COMMERCIAL

Rated Current Signal

1A

Connector Type

Receptacle

Çalışma Sıcaklığı

-55°C~85°C

Body Length Or Diameter

0.98 inch

Pozisyon Sayısı

16

Akım Değeri

1A

Style

Board to Board or Cable

Mil Conformance

NO

Insulation Resistance

1000000000Ohm

Number Of Pcb Rows

2

Reference Standard

UL

Applications

General Purpose

Contact Materials

Copper Alloy

REACH Uyumluluk Kodu

unknown

Contact Resistance

15mOhm

Contact Finish Mating

Gold
