Specifications
- Housing Color
- Brown
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Flammability Rating
- UL94 V-0
- Parça Durumu
- Active
- HTS Kodu
- 8536.69.40.40
- Insulation Resistance
- 1000000000Ohm
- Contact Finish
- Gold
- Total Number Of Contacts
- 90
- Seri
- FunctionMax™ FX8
- Terminal
- Solder
- Özellikler
- Board Guide
- Voltage Rated Ac
- 100V
- Connector Type
- Receptacle, Center Strip Contacts
- ECCN Kodu
- EAR99
- Montaj Tipi
- Surface Mount
- Filter Feature
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Contact Style
- BELLOWED TYPE
- Contact Pattern
- RECTANGULAR
- Contact Materials
- Bronze
- Lead Pitch
- 600μm
- Contact Resistance
- 45mOhm
- Dielectric Withstanding Voltage
- 300VAC V
- Number Of Conductors
- ONE
- Housing Material
- PBT
- Akım Değeri
- 400mA
- Pcb Contact Row Spacing
- 5.6896 mm
- Additional Feature
- LOW PROFILE
- Height Above Board
- 0.089 2.26mm
- Pitch
- 0.024 0.60mm
- Rated Current Signal
- 0.4A
- Kurşunsuz Kodu
- yes
- Durability
- 50 Cycles
- Mil Conformance
- NO
- Pozisyon Sayısı
- 90
- Iec Conformance
- NO
- Reliability
- COMMERCIAL
- Kurşunsuz
- Lead Free
