Volume pricing
- 1+ pcs$3.08
- 10+ pcs$2.91
- 100+ pcs$2.74
- 500+ pcs$2.59
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Montaj Tipi
- Surface Mount
- Pcb Contact Row Spacing
- 4.8006 mm
- Pcb Contact Pattern
- RECTANGULAR
- Stack Height Mating
- 7mm 8mm 9mm
- JESD-609 Kodu
- e2
- Mounting Option1
- GUIDE SLOT
- Dielectric Withstanding Voltage
- 300VAC V
- Operating Temperature Min
- -55°C
- Insulation Resistance
- 100000000Ohm
- Pitch
- 0.031 0.80mm
- Total Number Of Contacts
- 20
- Seri
- FX6
- Pozisyon Sayısı
- 20
- Operating Temperature Max
- 85°C
- Reliability
- COMMERCIAL
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Resistance
- 40mOhm
- Sıra Sayısı
- 2
- Mounting Option2
- LOCKING
- Contact Pattern
- RECTANGULAR
- Ambalaj
- Tray
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- PHOSPHOR BRONZE
- Connector Type
- Receptacle, Center Strip Contacts
- Polarization Key
- POLARIZED HOUSING
- Rated Current Signal
- 0.5A
- Contact Finish
- Gold
- Durability
- 100 Cycles
- Radyasyon Dayanımı
- No
- Number Of Pcb Rows
- 2
- Insulation Materials
- POLYPHENYLENE SULPHIDE
- Contact Gender
- FEMALE
- Terminal
- Solder
- Number Of Conductors
- ONE
- Height Above Board
- 0.236 6.00mm
- Contact Style
- BELLOWED TYPE
- Reference Standard
- UL
