Volume pricing
- 1+ pcs$3.16
- 10+ pcs$2.98
- 100+ pcs$2.81
- 500+ pcs$2.65
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Current Rating Amps
- 13A
- Insulation Materials
- Polyamide (PA), Nylon
- Insulation Color
- Black
- Pitch Mating
- 0.150 3.81mm
- Contact Shape
- Rectangular
- Mixed Contacts
- YES
- Contact Length Post
- 0.130 3.30mm
- Contact Materials
- Copper Alloy
- Contact Finish Thickness Mating
- 3.90μin 0.099μm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~105°C
- Number Of Positions Loaded
- All
- Montaj
- Through Hole
- Contact Finish Post
- Tin
- Material Flammability Rating
- UL94 V-0
- Fastening Type
- Latch Holder
- Orientation
- Straight
- Sıra Sayısı
- 1
- Özellikler
- Board Guide, Board Lock
- Pozisyon Sayısı
- 5
- Contact Resistance
- 2mOhm
- RoHS Durumu
- RoHS Compliant
- Applications
- General Purpose
- Style
- Board to Board
- ECCN Kodu
- EAR99
- Reach Svhc
- No SVHC
- Terminal
- Solder
- Nominal Gerilim
- 250V
- JESD-609 Kodu
- e3
- Ambalaj
- Tray
- Number Of Conductors
- ONE
- Contact Finish Thickness Post
- 39.4μin 1.00μm
- Montaj Tipi
- Through Hole
- Parça Durumu
- Active
- REACH Uyumluluk Kodu
- unknown
- Connector Type
- Receptacle
- Akım Değeri
- 10A
- Contact Type
- Female Blade Socket
- Reliability
- COMMERCIAL
- Insulation Height
- 0.630 16.00mm
