Specifications
- Contact Pattern
- RECTANGULAR
- Number Of Contacts
- 120
- Lead Pitch
- 1.27mm
- Mixed Contacts
- NO
- JESD-609 Kodu
- e4
- Ul Flammability Code
- 94V-0
- Housing Color
- Black
- Pcb Contact Pattern
- STAGGERED
- Bodyshell Style
- RECEPTACLE
- Mating Contact Pitch
- 0.05 inch
- REACH Uyumluluk Kodu
- unknown
- Contact Resistance
- 45mOhm
- Reference Standard
- UL
- Housing Material
- Plastic
- Montaj Stili
- STRAIGHT
- Operating Temperature Max
- 85°C
- Body Depth
- 0.138 inch
- Montaj Tipi
- BOARD
- Contact Materials
- Bronze
- Rated Current Signal
- 0.5A
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Kurşunsuz
- Contains Lead
- Body Length Or Diameter
- 3.396 inch
- Iec Conformance
- NO
- Flammability Rating
- UL94 V-0
- Insulation Resistance
- 1000000000Ohm
- Filter Feature
- NO
- Additional Feature
- STAGGERED CONFIGURATION, POLARIZED
- Number Of Pcb Rows
- 4
- Operating Temperature Min
- -55°C
- Length Termination
- 0.13 inch
- Contact Plating
- Gold
- RoHS Durumu
- Non-RoHS Compliant
- Termination Type
- SOLDER
- Parça Durumu
- Obsolete
- Dielectric Withstanding Voltage
- 300VAC V
- Pcb Contact Row Spacing
- 1.905 mm
- Sıra Sayısı
- 2
- Contact Style
- BELLOWED TYPE
- Mil Conformance
- NO
