Specifications
- Mating Contact Pitch
- 0.05 inch
- Bodyshell Style
- RECEPTACLE
- Pcb Contact Pattern
- STAGGERED
- Housing Color
- Black
- Ul Flammability Code
- 94V-0
- JESD-609 Kodu
- e4
- Mixed Contacts
- NO
- Lead Pitch
- 1.27mm
- Number Of Contacts
- 100
- Contact Pattern
- RECTANGULAR
- Body Depth
- 0.138 inch
- Operating Temperature Max
- 85°C
- Montaj Stili
- STRAIGHT
- Housing Material
- Plastic
- ECCN Kodu
- EAR99
- Reference Standard
- UL
- Contact Resistance
- 45mOhm
- REACH Uyumluluk Kodu
- unknown
- RoHS Durumu
- Non-RoHS Compliant
- Length Termination
- 0.13 inch
- Contact Plating
- Gold
- Operating Temperature Min
- -55°C
- Number Of Pcb Rows
- 4
- Additional Feature
- STAGGERED CONFIGURATION, POLARIZED
- Filter Feature
- NO
- HTS Kodu
- 8536.69.40.40
- Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
- Kurşunsuz
- Contains Lead
- Contact Materials
- Bronze
- Rated Current Signal
- 0.5A
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Montaj Tipi
- BOARD
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Contact Gender
- FEMALE
- Connector Type
- BOARD STACKING CONNECTOR
- Option
- GENERAL PURPOSE
- Dielectric Withstanding Voltage
- 300VAC V
