Request a quote for pricing
Priced by quantity and lead time.
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Termination Type
- SOLDER
- Contact Finish Mating
- NOT SPECIFIED
- Sıra Sayısı
- 2
- Mil Conformance
- NO
- Dielectric Withstanding Voltage
- 300VAC V
- Option
- GENERAL PURPOSE
- Terminal Adımı
- 1.27mm
- Connector Type
- BOARD STACKING CONNECTOR
- Reliability
- COMMERCIAL
- Din Conformance
- NO
- Contact Gender
- FEMALE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj Tipi
- BOARD
- Body Breadth
- 0.276 inch
- Rated Current Signal
- 0.5A
- Contact Materials
- NOT SPECIFIED
- Kurşunsuz
- Lead Free
- Body Length Or Diameter
- 2.096 inch
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 10 Weeks
- HTS Kodu
- 8536.69.40.40
- Insulation Resistance
- 1000000000Ohm
- Filter Feature
- NO
- Number Of Pcb Rows
- 4
- Operating Temperature Min
- -55°C
- Mounting Option1
- LOCKING
- Length Termination
- 0.118 inch
- RoHS Durumu
- RoHS Compliant
- REACH Uyumluluk Kodu
- unknown
- Contact Resistance
- 45mOhm
- Reference Standard
- UL
- ECCN Kodu
- EAR99
- Montaj Stili
- STRAIGHT
- Operating Temperature Max
- 85°C
- Body Depth
- 0.138 inch
- Total Number Of Contacts
- 68
- Contact Pattern
- STAGGERED
- Insulator Color
- BLACK
- Mixed Contacts
- NO
