Specifications
- Kurşunsuz
- Lead Free
- Contact Materials
- NOT SPECIFIED
- Rated Current Signal
- 0.5A
- Body Breadth
- 0.276 inch
- Montaj Tipi
- BOARD
- Body Length Or Diameter
- 0.896 inch
- Number Of Pcb Rows
- 4
- Filter Feature
- NO
- Insulation Resistance
- 1000000000Ohm
- Fabrika Tedarik Süresi
- 10 Weeks
- HTS Kodu
- 8536.69.40.40
- Iec Conformance
- NO
- RoHS Durumu
- RoHS Compliant
- Pin Sayısı
- 20
- Mounting Option1
- LOCKING
- Length Termination
- 0.118 inch
- Operating Temperature Min
- -55°C
- Dielectric Withstanding Voltage
- 300VAC V
- Mil Conformance
- NO
- Sıra Sayısı
- 2
- Contact Finish Mating
- NOT SPECIFIED
- Termination Type
- SOLDER
- Parça Durumu
- Active
- Option
- GENERAL PURPOSE
- Terminal Adımı
- 1.27mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Gender
- FEMALE
- Din Conformance
- NO
- Reliability
- COMMERCIAL
- Connector Type
- BOARD STACKING CONNECTOR
- Contact Pattern
- STAGGERED
- Total Number Of Contacts
- 20
- Ul Flammability Code
- 94V-0
- Insulator Color
- BLACK
- Mixed Contacts
- NO
- Bodyshell Style
- RECEPTACLE
- Pcb Contact Pattern
- STAGGERED
- Kurşunsuz Kodu
- no
- Mating Contact Pitch
- 0.05 inch
- Reference Standard
- UL
