Specifications
- Operating Temperature Max
- 85°C
- Iec Conformance
- NO
- Montaj Stili
- STRAIGHT
- Bodyshell Style
- RECEPTACLE
- RoHS Durumu
- Non-RoHS Compliant
- Ul Flammability Code
- 94V-0
- Kurşunsuz
- Contains Lead
- REACH Uyumluluk Kodu
- unknown
- Number Of Contacts
- 68
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Parça Durumu
- Obsolete
- Housing Material
- Plastic
- Dielectric Withstanding Voltage
- 300VAC V
- Mating Contact Pitch
- 0.05 inch
- Housing Color
- Black
- Pcb Contact Row Spacing
- 1.905 mm
- Option
- GENERAL PURPOSE
- Contact Pattern
- RECTANGULAR
- Body Depth
- 0.335 inch
- Gender
- Male
- Additional Feature
- POLARIZED, STAGGERED CONFIGURATION
- Lead Pitch
- 1.27mm
- Length Termination
- 0.13 inch
- Flammability Rating
- UL94 V-0
- Contact Finish Mating
- NOT SPECIFIED
- Termination Type
- SOLDER
- Mixed Contacts
- NO
- Filter Feature
- NO
- Contact Resistance
- 45mOhm
- Contact Materials
- Brass
- Mounting Option1
- LOCKING MECH
- Reliability
- COMMERCIAL
- Operating Temperature Min
- -55°C
- Reference Standard
- UL
- Connector Type
- BOARD CONNECTOR
- Pcb Contact Pattern
- STAGGERED
- Contact Plating
- Gold
- Din Conformance
- NO
- Number Of Pcb Rows
- 4
