Specifications
- Parça Durumu
- Active
- Terminal Adımı
- 2.54mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sıra Sayısı
- 2
- Dielectric Withstanding Voltage
- 300VAC V
- Mating Contact Pitch
- 0.05 inch
- Body Breadth
- 0.276 inch
- Pcb Contact Row Spacing
- 1.905 mm
- Pin Sayısı
- 60
- Contact Pattern
- RECTANGULAR
- Operating Temperature Max
- 85°C
- Body Length Or Diameter
- 2.194 inch
- Board Mounting Option
- LOCKPIN
- Number Of Conductors
- ONE
- Montaj Stili
- STRAIGHT
- RoHS Durumu
- RoHS Compliant
- Contact Gender
- MALE
- REACH Uyumluluk Kodu
- unknown
- Reliability
- COMMERCIAL
- Reference Standard
- UL
- Operating Temperature Min
- -55°C
- Connector Type
- BOARD CONNECTOR
- Pcb Contact Pattern
- STAGGERED
- Number Of Pcb Rows
- 4
- Montaj Tipi
- BOARD
- Total Number Of Contacts
- 60
- Insulation Resistance
- 1000000000Ohm
- Rated Current Signal
- 0.5A
- Body Depth
- 0.335 inch
- Durability
- 500 Cycles
- Length Termination
- 0.13 inch
- Termination Type
- SOLDER
- Contact Finish Mating
- AU
- Contact Style
- CENTRONIC
- Polarization Key
- POLARIZED HOUSING
- Mounting Option1
- LOCKING
- Contact Materials
- PHOSPHOR BRONZE
- Contact Resistance
- 45mOhm
- Insulation Materials
- POLYAMIDE
- Insulator Color
- BLACK
