Specifications
- Contact Pattern
- RECTANGULAR
- Pcb Contact Row Spacing
- 1.905 mm
- Option
- GENERAL PURPOSE
- Housing Material
- Polyamide
- Dielectric Withstanding Voltage
- 300VAC V
- Sıra Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Contacts
- 52
- Parça Durumu
- Active
- Pitch
- 1.27mm
- REACH Uyumluluk Kodu
- unknown
- Kurşunsuz
- Lead Free
- RoHS Durumu
- RoHS Compliant
- Ul Flammability Code
- 94V-0
- Renk
- Black
- Iec Conformance
- NO
- Body Length Or Diameter
- 1.994 inch
- ECCN Kodu
- EAR99
- Operating Temperature Max
- 85°C
- Fabrika Tedarik Süresi
- 10 Weeks
- Plating Thickness
- FLASH inch
- Nominal Gerilim
- 125V
- Akım Değeri
- 500mA
- Rated Current Signal
- 0.5A
- Insulation Resistance
- 1000000000Ohm
- Mil Conformance
- NO
- Din Conformance
- NO
- Contact Plating
- Gold
- JESD-609 Kodu
- e4
- Number Of Pcb Rows
- 4
- Pcb Contact Pattern
- STAGGERED
- Connector Type
- Center Strip Contact
- Operating Temperature Min
- -45°C
- Reference Standard
- UL
- Reliability
- COMMERCIAL
- Filter Feature
- NO
- Contact Resistance
- 45mOhm
- Contact Materials
- Bronze
- Mixed Contacts
- NO
- Montaj
- Through Hole
