Specifications
- Pitch
- 1.27mm
- Orientation
- Right Angle
- Operating Temperature Max
- 85°C
- Body Depth
- 0.591 inch
- Housing Material
- Polyphenylene
- ECCN Kodu
- EAR99
- Number Of Conductors
- ONE
- Contact Resistance
- 45mOhm
- Reference Standard
- UL
- Pcb Contact Pattern
- STAGGERED
- Polarization Key
- POLARIZED HOUSING
- Radyasyon Dayanımı
- No
- Housing Color
- Black
- Contact Pattern
- RECTANGULAR
- Number Of Contacts
- 80
- Lead Pitch
- 1.27mm
- Connector Type
- BOARD STACKING CONNECTOR
- Reliability
- COMMERCIAL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- Parça Durumu
- Active
- Contact Finish Mating
- AU
- Akım Değeri
- 500mA
- Sıra Sayısı
- 2
- Contact Style
- CENTRONIC
- Pcb Contact Row Spacing
- 1.905 mm
- Dielectric Withstanding Voltage
- 300VAC V
- Durability
- 500 Cycles
- Operating Temperature Min
- -55°C
- Mounting Option1
- LOCKING
- Contact Plating
- Gold
- Length Termination
- 0.13 inch
- Gender
- Male
- RoHS Durumu
- RoHS Compliant
- Flammability Rating
- UL94 V-0
- HTS Kodu
- 8536.69.40.40
- Fabrika Tedarik Süresi
- 10 Weeks
- Insulation Resistance
- 1000000000Ohm
- Number Of Pcb Rows
- 4
- Montaj Tipi
- BOARD
