Specifications
- Mixed Contacts
- NO
- JESD-609 Kodu
- e4
- Ul Flammability Code
- 94V-0
- Housing Color
- Black
- Contact Pattern
- RECTANGULAR
- Number Of Contacts
- 68
- Lead Pitch
- 1.27mm
- Mating Contact Pitch
- 0.05 inch
- Pcb Contact Pattern
- STAGGERED
- Bodyshell Style
- RECEPTACLE
- REACH Uyumluluk Kodu
- unknown
- Contact Resistance
- 45mOhm
- Reference Standard
- UL
- Montaj Stili
- RIGHT ANGLE
- Operating Temperature Max
- 85°C
- Body Depth
- 0.591 inch
- Housing Material
- Plastic
- Montaj Tipi
- BOARD
- Contact Materials
- Bronze
- Rated Current Signal
- 0.5A
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Kurşunsuz
- Contains Lead
- Operating Temperature Min
- -55°C
- Contact Plating
- Gold
- Length Termination
- 0.13 inch
- Gender
- Male
- RoHS Durumu
- Non-RoHS Compliant
- Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
- Filter Feature
- NO
- Insulation Resistance
- 1000000000Ohm
- Number Of Pcb Rows
- 4
- Additional Feature
- STAGGERED CONFIGURATION, POLARIZED
- Option
- GENERAL PURPOSE
- Parça Durumu
- Obsolete
- Termination Type
- SOLDER
- Pcb Contact Row Spacing
- 1.905 mm
- Mil Conformance
- NO
- Sıra Sayısı
- 2
- Dielectric Withstanding Voltage
- 300VAC V
