FX2-20S-1.27DS

Specifications

Body Length Or Diameter

0.896 inch

Montaj Tipi

Through Hole, Right Angle

Mating Information

MULTIPLE MATING PARTS AVAILABLE

Rated Current Signal

0.5A

Contact Materials

Bronze

Kurşunsuz

Contains Lead

Contact Finish

Gold

Operating Temperature Min

-55°C

Length Termination

0.13 inch

RoHS Durumu

Non-RoHS Compliant

Flammability Rating

UL94 V-0

Iec Conformance

NO

Insulation Resistance

1000000000Ohm

Filter Feature

NO

Number Of Pcb Rows

4

Additional Feature

STAGGERED CONFIGURATION, POLARIZED

Option

GENERAL PURPOSE

Parça Durumu

Obsolete

Terminal

Solder

Pozisyon Sayısı

20

Sıra Sayısı

2

Contact Style

BELLOWED TYPE

Mil Conformance

NO

Pcb Contact Row Spacing

1.905 mm

Dielectric Withstanding Voltage

300VAC V

Connector Type

Receptacle

Reliability

COMMERCIAL

Din Conformance

NO

Contact Gender

FEMALE

Seri

FX2

Nem Hassasiyeti (MSL)

1 (Unlimited)

Mixed Contacts

NO

JESD-609 Kodu

e4

Ul Flammability Code

94V-0

Housing Color

Black

Total Number Of Contacts

20

Contact Pattern

RECTANGULAR

Lead Pitch

1.27mm

Mating Contact Pitch

0.05 inch

Pcb Contact Pattern

STAGGERED
