Specifications
- Contact Pattern
- RECTANGULAR
- Total Number Of Contacts
- 20
- Housing Color
- Brown
- Ul Flammability Code
- 94V-0
- Mixed Contacts
- NO
- Bodyshell Style
- RECEPTACLE
- Pcb Contact Pattern
- RECTANGULAR
- Mating Contact Pitch
- 0.05 inch
- Reference Standard
- UL
- Contact Resistance
- 45mOhm
- REACH Uyumluluk Kodu
- unknown
- ECCN Kodu
- EAR99
- Housing Material
- Plastic
- Connector Style
- Center Strip Contacts
- Operating Temperature Max
- 85°C
- Body Depth
- 0.339 inch
- Kurşunsuz
- Contains Lead
- Rated Current Signal
- 0.5A
- Contact Materials
- Bronze
- Montaj Tipi
- Surface Mount
- Body Length Or Diameter
- 0.896 inch
- Additional Feature
- POLARIZED
- Number Of Pcb Rows
- 2
- Filter Feature
- NO
- Insulation Resistance
- 1000000000Ohm
- HTS Kodu
- 8536.69.40.40
- Iec Conformance
- NO
- Flammability Rating
- UL94 V-0
- RoHS Durumu
- Non-RoHS Compliant
- Operating Temperature Min
- -55°C
- Contact Finish
- Gold
- Dielectric Withstanding Voltage
- 300VAC V
- Pcb Contact Row Spacing
- 5.588 mm
- Mil Conformance
- NO
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 20
- Parça Durumu
- Obsolete
- Terminal
- Solder
- Option
- GENERAL PURPOSE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
