Specifications
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Rated Current Signal
- 0.5A
- Contact Materials
- Bronze
- Montaj Tipi
- Through Hole, Right Angle
- Kurşunsuz
- Contains Lead
- Body Length Or Diameter
- 3.396 inch
- Flammability Rating
- UL94 V-0
- Iec Conformance
- NO
- Additional Feature
- STAGGERED CONFIGURATION, POLARIZED
- Number Of Pcb Rows
- 4
- Filter Feature
- NO
- Insulation Resistance
- 1000000000Ohm
- Operating Temperature Min
- -55°C
- Contact Finish
- Gold
- RoHS Durumu
- Non-RoHS Compliant
- Length Termination
- 0.13 inch
- Terminal
- Solder
- Parça Durumu
- Obsolete
- Dielectric Withstanding Voltage
- 300VAC V
- Pcb Contact Row Spacing
- 1.905 mm
- Mil Conformance
- NO
- Contact Style
- BELLOWED TYPE
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 120
- Option
- GENERAL PURPOSE
- Din Conformance
- NO
- Contact Gender
- FEMALE
- Reliability
- COMMERCIAL
- Connector Type
- Receptacle
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Seri
- FX2
- Contact Pattern
- RECTANGULAR
- Total Number Of Contacts
- 120
- Lead Pitch
- 1.27mm
- Mixed Contacts
- NO
- Housing Color
- Black
- JESD-609 Kodu
- e4
- Ul Flammability Code
- 94V-0
- Tip
- Board to Board
- Pcb Contact Pattern
- STAGGERED
