Specifications
- Din Conformance
- NO
- Pcb Contact Pattern
- RECTANGULAR
- Insulation Materials
- LIQUID CRYSTAL POLYMER (LCP)
- Pozisyon Sayısı
- 116
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Finish Thickness
- 3.94μin 0.10μm
- Polarization Key
- POLARIZED HOUSING
- Connector Type
- Receptacle, Center Strip Contacts
- Insulator Color
- BEIGE
- Mil Conformance
- NO
- Contact Materials
- NOT SPECIFIED
- Insulation Resistance
- 100000000Ohm
- Option
- GENERAL PURPOSE
- Pitch
- 0.020 0.50mm
- Filter Feature
- NO
- Mixed Contacts
- NO
- Contact Gender
- FEMALE
- RoHS Durumu
- RoHS Compliant
- Body Length Or Diameter
- 1.457 inch
- Terminal
- SMD/SMT
- Reference Standard
- UL
- Total Number Of Contacts
- 116
- Operating Temperature Max
- 85°C
- Rated Current Signal
- 0.3A
- Parça Durumu
- Active
- Durability
- 50 Cycles
- Iec Conformance
- NO
- Number Of Conductors
- ONE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Temperature Min
- -55°C
- Stack Height
- 2mm
- Pcb Contact Row Spacing
- 5.6896 mm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 2
- Additional Feature
- HIGH DENSITY, LOW PROFILE
- Contact Resistance
- 70mOhm
- REACH Uyumluluk Kodu
- unknown
- Kurşunsuz Kodu
- yes
- Contact Finish
- Gold
