Volume pricing
- 1+ pcs$3.65
- 10+ pcs$3.45
- 100+ pcs$3.25
- 500+ pcs$3.07
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Flammability Rating
- UL94 V-0
- Terminal
- IDC
- Contact Materials
- COPPER ALLOY
- Din Conformance
- NO
- HTS Kodu
- 8536.69.40.30
- Connector Style
- Center Strip Contacts
- Min. Çalışma Sıcaklığı
- -55°C
- Kurşunsuz Kodu
- yes
- Housing Color
- Black
- Contact Resistance
- 35mOhm
- Tip
- Miniature High Density (HD)
- Option
- GENERAL PURPOSE
- Max Current Rating
- 500mA
- RoHS Durumu
- RoHS Compliant
- Depth
- 9.1mm
- Contact Finish
- Gold
- Yayın Yılı
- 2005
- Rated Current Signal
- 0.5A
- Reliability
- COMMERCIAL
- Akım Değeri
- 500mA
- Voltage Rated Ac
- 125V
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Uzunluk
- 20.9mm
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Steel
- Gender
- Male
- Maks. Çalışma Sıcaklığı
- 85°C
- Contact Style
- CENTRONIC
- Pitch
- 1.27mm
- Montaj Tipi
- Free Hanging (In-Line)
- Ambalaj
- Bulk
- Ul Flammability Code
- 94V-0
- Montaj
- Free Hanging
- Seri
- DXM
- Parça Durumu
- Active
- Kurşunsuz
- Lead Free
- Mixed Contacts
- NO
- Lead Pitch
- 1.27mm
- Reference Standard
- UL
- Pozisyon Sayısı
- 20
