Specifications
- Tip
- Miniature High Density (HD)
- Min. Çalışma Sıcaklığı
- -55°C
- Connector Style
- Center Strip Contacts
- Contact Resistance
- 35mOhm
- Kurşunsuz Kodu
- yes
- Contact Finish
- Gold
- Option
- GENERAL PURPOSE
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- COPPER ALLOY
- Flammability Rating
- UL94 V-0
- Dielectric Withstanding Voltage
- 300VAC V
- Terminal
- IDC
- Din Conformance
- NO
- HTS Kodu
- 8536.69.40.30
- Housing Material
- Steel
- Contact Design
- PREASSEM CONN
- REACH Uyumluluk Kodu
- unknown
- Gender
- Male
- Maks. Çalışma Sıcaklığı
- 85°C
- Body Length Or Diameter
- 3.073 inch
- Rated Current Signal
- 0.5A
- Reliability
- COMMERCIAL
- Yayın Yılı
- 2012
- Insulator Color
- BLACK
- Voltage Rated Ac
- 125V
- Akım Değeri
- 500mA
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Reference Standard
- UL
- Parça Durumu
- Active
- Seri
- DXM
- Mixed Contacts
- NO
- Pozisyon Sayısı
- 110
- Sıra Sayısı
- 2
- Contact Pattern
- RECTANGULAR
- Empty Shell
- NO
- Pitch
- 1.27mm
- Montaj Tipi
- Free Hanging (In-Line)
- Ul Flammability Code
- 94V-0
- Insulation Materials
- PBT
- Montaj
- Free Hanging
