Specifications
- Housing Material
- Zinc
- Wire Size Min
- 30 AWG
- REACH Uyumluluk Kodu
- unknown
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Style
- CENTRONIC
- Number Of Ports
- 1
- Wire Size Max
- 28 AWG
- Contact Plating
- Gold
- Gender
- Male
- Maks. Çalışma Sıcaklığı
- 85°C
- Insulation Resistance
- 250MOhm
- Shell Finish
- SILVER
- Rated Current Signal
- 0.5A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reliability
- COMMERCIAL
- Max Voltage Rating Ac
- 125V
- Yayın Yılı
- 2012
- Insulator Color
- BLACK
- Total Number Of Contacts
- 50
- Connector Type
- TELECOM AND DATACOM CONNECTOR
- ECCN Kodu
- EAR99
- Orientation
- Right Angle
- Contact Finish Mating
- AU
- Voltage Rated Ac
- 125V
- Akım Değeri
- 500mA
- Uzunluk
- 38.23mm
- Reference Standard
- UL
- Bodyshell Style
- PLUG
- Parça Durumu
- Active
- Min. Çalışma Sıcaklığı
- -55°C
- Depth
- 17.2mm
- Contact Pattern
- RECTANGULAR
- Terminal Sayısı
- 50
- Sıra Sayısı
- 2
- Mounting Option1
- LOCKING
- Max Current Rating
- 500mA
- RoHS Durumu
- RoHS Compliant
- Contact Materials
- COPPER ALLOY
- Pitch
- 1.27mm
- Dielectric Withstanding Voltage
- 424VAC V
