Specifications
- Option
- GENERAL PURPOSE
- RoHS Durumu
- Non-RoHS Compliant
- Contact Finish
- Gold
- Pozisyon Sayısı
- 80
- Sıra Sayısı
- 2
- Contact Pattern
- RECTANGULAR
- Empty Shell
- NO
- Parça Durumu
- Obsolete
- Connector Style
- Outer Shroud Contacts
- Seri
- DXM
- Mixed Contacts
- NO
- Contact Resistance
- 35mOhm
- Kurşunsuz
- Contains Lead
- Housing Color
- Black
- Tip
- Miniature High Density (HD)
- Reference Standard
- UL
- Additional Feature
- SCREW LOCK TYPE
- Shell Material
- STEEL
- Din Conformance
- NO
- Ul Flammability Code
- 94V-0
- Montaj
- Panel, Through Hole
- Dielectric Withstanding Voltage
- 300VAC V
- Terminal
- Solder
- Flange Feature
- Mating Side, Female Screwlock (M2.6)
- Montaj Tipi
- Panel Mount, Through Hole
- Ambalaj
- Bulk
- Contact Materials
- COPPER ALLOY
- Number Of Pcb Rows
- 4
- Contact Style
- BELLOWED TYPE
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Plastic
- Mating Contact Pitch
- 0.05 inch
- Pcb Contact Pattern
- STAGGERED
- Filter Feature
- NO
- Body Breadth
- 0.354 inch
- Iec Conformance
- NO
- JESD-609 Kodu
- e4
- Pcb Contact Row Spacing
- 1.905 mm
- Connector Type
- Receptacle
- Total Number Of Contacts
- 80
