Specifications
- Shell Material
- STEEL
- Montaj
- Panel, Through Hole
- Din Conformance
- NO
- Ul Flammability Code
- 94V-0
- Montaj Tipi
- Panel Mount, Through Hole
- Ambalaj
- Bulk
- Terminal
- Solder
- Flange Feature
- Mating Side, Female Screwlock (M2.6)
- Flammability Rating
- UL94 V-0
- Dielectric Withstanding Voltage
- 100VDC V
- Number Of Pcb Rows
- 4
- Contact Materials
- COPPER ALLOY
- RoHS Durumu
- Non-RoHS Compliant
- Option
- GENERAL PURPOSE
- Empty Shell
- NO
- Contact Pattern
- RECTANGULAR
- Sıra Sayısı
- 2
- Pozisyon Sayısı
- 68
- Contact Finish
- Gold
- Housing Color
- Black
- Kurşunsuz
- Contains Lead
- Contact Resistance
- 35mOhm
- Mixed Contacts
- NO
- Connector Style
- Outer Shroud Contacts
- Seri
- DXM
- Parça Durumu
- Obsolete
- Reference Standard
- UL
- Tip
- Miniature High Density (HD)
- Body Breadth
- 0.354 inch
- Filter Feature
- NO
- Pcb Contact Row Spacing
- 1.905 mm
- Iec Conformance
- NO
- JESD-609 Kodu
- e4
- Connector Type
- Receptacle
- Total Number Of Contacts
- 68
- Yayın Yılı
- 2005
- Mil Conformance
- NO
- Reliability
- COMMERCIAL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Rated Current Signal
- 0.5A
