Volume pricing
- 1+ pcs$8.65
- 10+ pcs$8.16
- 100+ pcs$7.69
- 500+ pcs$7.26
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- RoHS Compliant
- Max Current Rating
- 500mA
- Option
- GENERAL PURPOSE
- Sıra Sayısı
- 2
- Empty Shell
- NO
- Contact Finish
- Gold
- Pozisyon Sayısı
- 36
- Depth
- 16.7mm
- Mixed Contacts
- NO
- Kurşunsuz Kodu
- yes
- Min. Çalışma Sıcaklığı
- -55°C
- Parça Durumu
- Active
- Connector Style
- Outer Shroud Contacts
- Seri
- DXM
- Tip
- Miniature High Density (HD)
- Shell Material
- STEEL
- Montaj
- Panel, Through Hole
- Din Conformance
- NO
- Ul Flammability Code
- 94V-0
- Insulation Materials
- PBT
- Terminal
- Solder
- Flange Feature
- Housing/Shell (M2.6)
- Montaj Tipi
- Panel Mount, Through Hole, Right Angle
- Pitch
- 1.27mm
- Contact Materials
- COPPER ALLOY
- Maks. Çalışma Sıcaklığı
- 85°C
- Insulation Resistance
- 250MOhm
- Gender
- Female
- Fabrika Tedarik Süresi
- 8 Weeks
- Number Of Ports
- 1
- REACH Uyumluluk Kodu
- unknown
- Housing Material
- Zinc
- Nominal Gerilim
- 125V
- Filter Feature
- NO
- Uzunluk
- 43.51mm
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Akım Değeri
- 500mA
- Özellikler
- Board Lock
- Orientation
- Right Angle
- JESD-609 Kodu
- e4
