Specifications
- Kurşunsuz Kodu
- yes
- Flammability Rating
- UL94 V-0
- Reference Standard
- UL
- Montaj
- Surface Mount
- Pin Sayısı
- 9
- Number Of Contacts
- 8
- Pitch
- 1.1mm
- RoHS Durumu
- RoHS Compliant
- Depth
- 1.83mm
- Durability
- 5000 Cycles
- Reach Svhc
- Unknown
- JESD-609 Kodu
- e3
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Materials
- Copper
- Din Conformance
- NO
- Yayın Yılı
- 2010
- Akım Değeri
- 500mA
- Maks. Çalışma Sıcaklığı
- 85°C
- Uzunluk
- 14.1mm
- Mounting Feature
- Normal, Standard - Top
- Voltage Rated Ac
- 125V
- Pozisyon Sayısı
- 10 (8 + 2)
- Height Above Board
- 0.072 1.83mm
- Option
- GENERAL PURPOSE
- Bodyshell Style
- RECEPTACLE
- Radyasyon Dayanımı
- No
- Reliability
- COMMERCIAL
- Terminal
- Solder
- Number Of Conductors
- ONE
- Dielectric Withstanding Voltage
- 500VAC V
- Ambalaj
- Tape & Reel (TR)
- Contact Resistance
- 100mOhm
- Contact Pattern
- RECTANGULAR
- Housing Material
- Polymer
- Seri
- DM3
- Iec Conformance
- NO
- Orientation
- Right Angle
- Mil Conformance
- NO
- Insertion Removal Method
- Hinged Lid
- Insulation Resistance
- 1GOhm
