DF9-15P-1V(32)

Specifications

Contact Materials

Copper

Ambalaj

Tape & Reel (TR)

Montaj Tipi

Surface Mount

Terminal

SMD/SMT

Contact Finish Thickness

39.4μin 1.00μm

Flammability Rating

UL94 V-0

Pitch

0.039 1.00mm

Montaj

Surface Mount

Ul Flammability Code

94V-0

Din Conformance

NO

Additional Feature

POLARIZED

Lead Pitch

1mm

Housing Color

Beige

Kurşunsuz

Lead Free

Kurşunsuz Kodu

yes

Mixed Contacts

NO

Seri

DF9

Parça Durumu

Active

Sıra Sayısı

2

Pozisyon Sayısı

15

Stack Height Mating

4.3mm

Contact Finish

Tin

RoHS Durumu

RoHS Compliant

Option

GENERAL PURPOSE

Radyasyon Dayanımı

No

Mil Conformance

NO

Nem Hassasiyeti (MSL)

1 (Unlimited)

Total Number Of Contacts

15

Connector Type

Header, Center Strip Contacts

Orientation

Straight

Özellikler

Board Guide, Solder Retention

Iec Conformance

NO

Filter Feature

NO

Nominal Gerilim

150V

Akım Değeri

500mA

Height Above Board

0.130 3.30mm

Housing Material

Polyamide

Fabrika Tedarik Süresi

10 Weeks

Reach Svhc

Unknown

Gender

Male
