Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Montaj
- Surface Mount
- Contact Gender
- FEMALE
- Option
- GENERAL PURPOSE
- Total Number Of Contacts
- 30
- Orientation
- Straight
- Additional Feature
- LOW PROFILE
- Contact Finish
- Gold
- Kurşunsuz Kodu
- yes
- Height Above Board
- 0.035 0.88mm
- Housing Color
- Black
- Nominal Gerilim
- 30V
- Flammability Rating
- UL94 V-0
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 8.22mm
- Maks. Çalışma Sıcaklığı
- 85°C
- Contact Resistance
- 100mOhm
- Seri
- DF30
- Stack Height Mating
- 0.9mm
- ECCN Kodu
- EAR99
- Terminal
- Solder
- Connector Type
- Receptacle, Outer Shroud Contacts
- Fabrika Tedarik Süresi
- 10 Weeks
- JESD-609 Kodu
- e4
- Akım Değeri
- 300mA
- Din Conformance
- NO
- Pozisyon Sayısı
- 30
- Mixed Contacts
- NO
- Stack Height
- 900μm
- Ul Flammability Code
- 94V-0
- Filter Feature
- NO
- Contact Materials
- Bronze
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Depth
- 3.76mm
- Montaj Tipi
- Surface Mount
- HTS Kodu
- 8536.69.40.40
- Kurşunsuz
- Lead Free
- Housing Material
- Polymer
- Sıra Sayısı
- 2
- Iec Conformance
- NO
- Ambalaj
- Tape & Reel (TR)
