60110145732

Specifications

Empty Shell

NO

Pitch

1.27mm

Insulator Color

BLACK

Montaj Tipi

Panel Mount, Through Hole, Right Angle

Kılıf / Paket

SMC

Shell Material

STEEL

Body Breadth

0.366 inch

Insulation Materials

Polymer

Connector Type

Receptacle

Operating Temperature Max

105°C

Gender

Female

Parça Durumu

Obsolete

Tip

SCSI

Length Termination

0.116 inch

Seri

har-mik®

Sıra Sayısı

2

Contact Resistance

45mOhm

Mixed Contacts

NO

Body Depth

0.447 inch

Pozisyon Sayısı

14

Contact Style

BELLOWED TYPE

Iec Conformance

NO

Contact Finish

Gold

Reliability

COMMERCIAL

Din Conformance

NO

Terminal

Solder

Akım Değeri

1A

Ul Flammability Code

94V-0

Connector Style

Outer Shroud Contacts

Flange Feature

Housing/Shell (M2.6)

Contact Materials

COPPER ALLOY

RoHS Durumu

RoHS Compliant

Filter Feature

NO

Operating Temperature Min

-55°C

Body Length Or Diameter

1.163 inch

Insulation

Insulated

Mil Conformance

NO

Reference Standard

UL

Mating Contact Row Spacing

0.098 inch

Pcb Contact Pattern

STAGGERED
