Specifications
- Montaj Tipi
- Through Hole
- Total Number Of Contacts
- 132
- Filter Feature
- NO
- Ambalaj
- Tube
- RoHS Durumu
- ROHS3 Compliant
- Ul Flammability Code
- 94V-0
- Sıra Sayısı
- 5 + 1
- Depth
- 15.4mm
- Contact Plating
- Gold
- Uzunluk
- 44mm
- Pozisyon Sayısı
- 132 (110 + 22 Ground)
- Mil Conformance
- NO
- Kurşunsuz Kodu
- yes
- Seri
- har-bus® HM
- Option
- GENERAL PURPOSE
- Connector Type
- Header, Male Pins
- Orientation
- Straight
- Pitch
- 0.079 2.00mm
- Number Of Positions Loaded
- All
- Connector Style
- B 22
- Iec Conformance
- NO
- Current Rating Amps
- 1A
- Din Conformance
- NO
- Contact Finish Thickness
- Flash
- Additional Feature
- 22 GROUND SHIELD CONTACTS IN 1 ROW AVAILABLE
- Mixed Contacts
- NO
- Contact Finish
- Gold or Gold-Palladium
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Materials
- NOT SPECIFIED
- JESD-609 Kodu
- e4
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Press-Fit
- Fabrika Tedarik Süresi
- 7 Weeks
