Volume pricing
- 1+ pcs$5.83
- 10+ pcs$5.50
- 100+ pcs$5.19
- 500+ pcs$4.90
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Conductors
- ONE
- Kurşunsuz
- Lead Free
- Polarization Key
- POLARIZED HOUSING
- Pcb Contact Row Spacing
- 5.4864 mm
- Fabrika Tedarik Süresi
- 5 Weeks
- Insertion Forcemax
- .5004 N
- Reliability
- COMMERCIAL
- Montaj Tipi
- Surface Mount
- Connector Type
- Receptacle
- Contact Shape
- Square
- Contact Type
- Female Socket
- Ambalaj
- Cut Tape (CT)
- Stack Height Mating
- 10.8mm ~ 13.8mm
- Özellikler
- Board Guide, Pick and Place, Solder Retention
- Terminal
- Solder
- Pozisyon Sayısı
- 40
- Insulation Color
- Black
- Style
- Board to Board or Cable
- Durability
- 500 Cycles
- Mating Contact Pitch
- 0.05 inch
- Sıra Sayısı
- 2
- Contact Finish Post
- Tin
- Orientation
- Straight
- Housing Material
- Liquid Crystal Polymer
- Çalışma Sıcaklığı
- -55°C~125°C
- Material Flammability Rating
- UL94 V-0
- Number Of Positions Loaded
- All
- Stack Height
- 9.05mm
- Montaj
- Surface Mount
- Fastening Type
- Push-Pull
- Akım Değeri
- 2A
- Applications
- General Purpose
- Insulation Materials
- Liquid Crystal Polymer (LCP)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Reference Standard
- UL
- Body Depth
- 0.356 inch
- Row Spacing Mating
- 0.050 (1.27mm)
- Parça Durumu
- Active
- Pitch Mating
- 0.050 1.27mm
- Contact Materials
- Copper Alloy
