Volume pricing
- 1+ pcs$3.78
- 10+ pcs$3.57
- 100+ pcs$3.37
- 500+ pcs$3.18
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Finish
- Gold
- Ambalaj
- Bulk
- Withdrawl Forcemin
- 1.5568 N
- Sıra Sayısı
- 3
- Reference Standard
- VDE,CSA
- Name Of Rows Loaded
- A,B,C
- Lead Length
- 4mm
- Rated Current Signal
- 2A
- Uzunluk
- 95mm
- Terminal
- Solder
- Flammability Rating
- UL94 V-0
- Contact Resistance
- 15MOhm
- Akım Değeri
- 2A
- Dielectric Withstanding Voltage
- 1000VAC V
- Working Voltage
- 250V
- Connector Type
- Header, Male Pins
- Ul Flammability Code
- 94V-0
- RoHS Durumu
- ROHS3 Compliant
- Test Voltage
- 1kV
- Iec Conformance
- NO
- Level Class
- 2
- Din Conformance
- YES
- Mating Contact Row Spacing
- 0.1 inch
- JESD-609 Kodu
- e4
- Max Current Rating
- 2A
- Montaj
- Panel, Through Hole
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 250V
- Number Of Pcb Rows
- 3
- Pozisyon Sayısı
- 96
- Depth
- 11.1mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Insulation Resistance
- 1000000000000Ohm
- Min. Çalışma Sıcaklığı
- -65°C
- Number Of Positions Loaded
- All
- Seri
- DIN 41612
- Length Tail
- 4mm
- Onay Kuruluşu
- IEC
- Montaj Tipi
- Panel Mount, Through Hole
- Housing Material
- Thermoplastic
