Volume pricing
- 1+ pcs$10.90
- 10+ pcs$10.28
- 100+ pcs$9.70
- 500+ pcs$9.15
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Total Number Of Contacts
- 24
- Din Conformance
- YES
- Fabrika Tedarik Süresi
- 9 Weeks
- Mil Conformance
- NO
- RoHS Durumu
- ROHS3 Compliant
- Dielectric Material
- Polyester Thermoplastic, Glass Filled
- Iec Conformance
- NO
- Shell Size Connector Layout
- 5 DD D - 24W7
- Montaj Tipi
- Free Hanging (In-Line)
- Housing Material
- Glass
- Ul Flammability Code
- 94V-0
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 14.5mm
- Pozisyon Sayısı
- 24 (17 + 7 Coax or Power)
- Contact Plating
- Gold
- Contact Materials
- NOT SPECIFIED
- Montaj
- Free Hanging, Panel
- Mixed Contacts
- YES
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Gender
- Receptacle
- Filter Feature
- NO
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Orientation
- Straight
- Option
- GENERAL PURPOSE
- Terminal
- Solder Cup
- Uzunluk
- 66.9mm
- Wire Gauge
- 20 AWG
- Material Flammability Rating
- UL94 V-0
- Genişlik
- 15.4mm
- Çalışma Sıcaklığı
- -55°C~125°C
- Shell Material Finish
- Steel, Tin Plated
- Ambalaj
- Bulk
- Contact Finish Mating
- NOT SPECIFIED
- Sıra Sayısı
- 2
- Flange Feature
- Housing/Shell (Unthreaded)
- Connector Type
- Receptacle, Female Sockets
- Renk
- Green
- Connector Style
- D-Sub, Combo
- Empty Shell
- YES
