Volume pricing
- 1+ pcs$5.65
- 10+ pcs$5.33
- 100+ pcs$5.03
- 500+ pcs$4.75
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Max Current Rating
- 5A
- Yükseklik
- 12.5mm
- Contact Type
- Signal and Coax or Power
- Shell Material Finish
- Steel, Tin Plated
- Contact Materials
- NOT SPECIFIED
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Option
- GENERAL PURPOSE
- Din Conformance
- NO
- Flange Feature
- Housing/Shell (Unthreaded)
- Mixed Contacts
- YES
- Note
- Contacts Not Included
- Shell Size Connector Layout
- 3 DB B - 13C3 13W3
- Iec Conformance
- NO
- Çalışma Sıcaklığı
- -55°C~125°C
- Sıra Sayısı
- 2
- Mil Conformance
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Orientation
- Straight
- Akım Değeri
- 5A
- Pozisyon Sayısı
- 13 (10 + 3 Coax or Power)
- Montaj Tipi
- Free Hanging (In-Line)
- Terminal
- Through Hole
- Montaj
- Free Hanging
- Contact Finish Mating
- NOT SPECIFIED
- Fabrika Tedarik Süresi
- 7 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Parça Durumu
- Active
- Total Number Of Contacts
- 13
- Depth
- 16.9mm
- Empty Shell
- NO
- Plating
- Tin
- Uzunluk
- 53mm
- Ambalaj
- Bulk
- Kurşunsuz Kodu
- yes
- Connector Style
- D-Sub, Combo
- Connector Type
- Receptacle for Female Contacts
- Ul Flammability Code
- 94V-0
- Genişlik
- 12.5mm
- Gender
- Receptacle
- Filter Feature
- NO
