09692000033

Specifications

Flange Feature

Housing/Shell (Unthreaded)

Note

Contacts Not Included

Mixed Contacts

NO

Body Breadth

0.492 inch

Shell Size Connector Layout

2 DA A - 3W3

Contact Type

Coax or Power

Din Conformance

YES

Contact Plating

Gold

Çalışma Sıcaklığı

-55°C~125°C

Iec Conformance

NO

Reference Standard

UL

Orientation

Straight

Pozisyon Sayısı

3 (Coax or Power)

Voltage Rated Dc

750V

Body Plating

Tin

Bodyshell Style

PLUG

Empty Shell

NO

Ambalaj

Bulk

Uzunluk

39.1mm

Flammability Rating

UL94 V-0

Kurşunsuz Kodu

yes

Fabrika Tedarik Süresi

4 Weeks

Contact Finish Mating

NOT SPECIFIED

RoHS Durumu

ROHS3 Compliant

Filter Feature

NO

Gender

Receptacle

Ul Flammability Code

94V-0

Connector Type

Receptacle for Female Contacts

Durability

500 Cycles

Pitch

6.86mm

Shell Material Finish

Steel, Tin Plated

Option

GENERAL PURPOSE

Dielectric Material

Polyester, Glass Filled

Body Material

Metal, Steel

Montaj Tipi

Free Hanging (In-Line)

Terminal

Solder

Material

Steel

Mil Conformance

NO

Sıra Sayısı

1

Nem Hassasiyeti (MSL)

1 (Unlimited)
