Volume pricing
- 1+ pcs$3.88
- 10+ pcs$3.66
- 100+ pcs$3.46
- 500+ pcs$3.26
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- ECCN Kodu
- EAR99
- Din Conformance
- YES
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Materials
- Copper Alloy
- Contact Type
- Signal
- Body Breadth
- 0.494 inch
- Shell Size Connector Layout
- 4 DC C
- Mixed Contacts
- NO
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Number Of Pcb Rows
- 2
- Pozisyon Sayısı
- 37
- Çalışma Sıcaklığı
- -55°C~125°C
- Iec Conformance
- YES
- Reference Standard
- UL
- Insertion Forcemax
- 3.336 N
- Mating Contact Pitch
- 0.109 inch
- RoHS Durumu
- ROHS3 Compliant
- Fabrika Tedarik Süresi
- 9 Weeks
- Contact Finish Mating
- NOT SPECIFIED
- Kurşunsuz Kodu
- yes
- Özellikler
- Board Lock
- Ambalaj
- Bulk
- Empty Shell
- NO
- Bodyshell Style
- PLUG
- Backset Spacing
- 0.318 (8.08mm)
- Total Number Of Contacts
- 37
- Ul Flammability Code
- 94V-0
- Connector Type
- Receptacle, Female Sockets
- HTS Kodu
- 8536.69.40.30
- Filter Feature
- NO
- Gender
- Receptacle
- Kurşunsuz
- Lead Free
- Pcb Contact Pattern
- STAGGERED
- Option
- GENERAL PURPOSE
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Contact Resistance
- 10mOhm
- Shell Material Finish
- Steel
- Akım Değeri
- 5A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Withdrawl Forcemin
- 3.336 N
