Volume pricing
- 1+ pcs$4.55
- 10+ pcs$4.29
- 100+ pcs$4.05
- 500+ pcs$3.82
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pcb Contact Pattern
- STAGGERED
- Gender
- Receptacle
- Contact Finish
- Gold or Gold-Palladium
- Filter Feature
- NO
- Plating Thickness
- 30μin
- Connector Type
- Receptacle, Female Sockets
- Ul Flammability Code
- 94V-0
- HTS Kodu
- 8536.69.40.30
- Empty Shell
- NO
- Bodyshell Style
- PLUG
- Total Number Of Contacts
- 25
- Backset Spacing
- 0.318 (8.08mm)
- Özellikler
- Board Lock
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Uzunluk
- 53.1mm
- Fabrika Tedarik Süresi
- 9 Weeks
- RoHS Durumu
- ROHS3 Compliant
- Insertion Forcemax
- 3.336 N
- Contact Plating
- Gold
- Reference Standard
- UL
- Iec Conformance
- YES
- Çalışma Sıcaklığı
- -55°C~125°C
- Orientation
- Straight
- Mixed Contacts
- NO
- Number Of Pcb Rows
- 2
- Flange Feature
- Housing/Shell (4-40)
- Terminal Sayısı
- 25
- Body Breadth
- 0.494 inch
- Shell Size Connector Layout
- 3 DB B
- Contact Type
- Signal
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Materials
- Copper Alloy
- Din Conformance
- YES
- ECCN Kodu
- EAR99
- Contact Finish Thickness
- 30.0μin 0.76μm
- Kontak Formu
- Stamped
- Housing Material
- PBT
- Reliability
- COMMERCIAL
- Current Rating Amps
- 6.5A
