Volume pricing
- 1+ pcs$13.23
- 10+ pcs$12.48
- 100+ pcs$11.77
- 500+ pcs$11.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Resistance
- 10mOhm
- Shell Material Finish
- Steel
- Option
- GENERAL PURPOSE
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Material Flammability Rating
- UL94 V-0
- Montaj Tipi
- Free Hanging (In-Line)
- Terminal
- Solder Cup
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 7A
- Mil Conformance
- NO
- Sıra Sayısı
- 3
- Contact Design
- PREASSEM CONN
- Parça Durumu
- Active
- Montaj
- Free Hanging
- Dielectric Withstanding Voltage
- 1000VAC V
- Housing Material
- PBT
- Mating Contact Row Spacing
- 0.112 inch
- Kontak Formu
- Machined
- Insulation Resistance
- 10000000000Ohm
- Shell Finish
- TIN
- Connector Style
- D-Sub
- Current Rating Amps
- 7.5A
- Shell Size Connector Layout
- 5 DD D
- Body Breadth
- 0.606 inch
- Flange Feature
- Housing/Shell (Unthreaded)
- Mixed Contacts
- NO
- ECCN Kodu
- EAR99
- Din Conformance
- NO
- Contact Materials
- Copper Alloy
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Contact Type
- Signal
- Mating Contact Pitch
- 0.108 inch
- Additional Feature
- STANDARDS: DIN 41652; IEC 60807
- Pozisyon Sayısı
- 50
- Çalışma Sıcaklığı
- -55°C~125°C
- Reference Standard
- UL
- Iec Conformance
- NO
- Ambalaj
- Bulk
- Kurşunsuz Kodu
- yes
- Özellikler
- Grounding Indents
