Volume pricing
- 1+ pcs$7.02
- 10+ pcs$6.62
- 100+ pcs$6.24
- 500+ pcs$5.89
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Çalışma Sıcaklığı
- -55°C~125°C
- Contact Design
- PREASSEM CONN
- Mil Conformance
- NO
- Shell Size Connector Layout
- 3 DB B
- Connector Type
- Receptacle, Female Sockets
- Material
- Liquid Crystal Polymer, Polymer
- Mixed Contacts
- NO
- Ambalaj
- Bulk
- Material Flammability Rating
- UL94 V-0
- Total Number Of Contacts
- 25
- Iec Conformance
- NO
- ECCN Kodu
- EAR99
- Bodyshell Style
- PLUG
- Montaj
- Free Hanging
- Kontak Formu
- Machined
- Sıra Sayısı
- 2
- Empty Shell
- NO
- Current Rating Amps
- 7.5A
- Uzunluk
- 53.2mm
- Withdrawl Forcemin
- 3.336 N
- Contact Type
- Signal
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Test Voltage
- 1kV
- Insertion Forcemax
- 3.336 N
- Depth
- 17mm
- Parça Durumu
- Active
- Housing Material
- Polybutylene
- Contact Finish Mating
- NOT SPECIFIED
- Terminal Sayısı
- 25
- Orientation
- Straight
- Option
- GENERAL PURPOSE
- Connector Style
- D-Sub
- RoHS Durumu
- ROHS3 Compliant
- Ul Flammability Code
- 94V-0
- Flange Feature
- Housing/Shell (Unthreaded)
- Contact Materials
- Copper Alloy
- Wire Gauge
- 20 AWG
- Terminal
- Solder Cup
- Reference Standard
- UL
- Kurşunsuz Kodu
- yes
