Volume pricing
- 1+ pcs$10.09
- 10+ pcs$9.52
- 100+ pcs$8.98
- 500+ pcs$8.47
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- HTS Kodu
- 8536.69.40.30
- Shell Material Finish
- Steel
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Gender
- Female
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Din Conformance
- YES
- Montaj Tipi
- Through Hole
- Fabrika Tedarik Süresi
- 7 Weeks
- Filter Feature
- NO
- Shell Finish
- TIN
- Number Of Ports
- 1
- Kurşunsuz Kodu
- yes
- Reference Standard
- UL
- Terminal
- Solder
- Contact Materials
- Copper Alloy
- Flange Feature
- Housing/Shell (4-40)
- Ul Flammability Code
- 94V-0
- RoHS Durumu
- ROHS3 Compliant
- Connector Style
- D-Sub
- Option
- GENERAL PURPOSE
- Orientation
- Straight
- Terminal Sayısı
- 37
- Housing Material
- Polybutylene
- Contact Finish Mating
- NOT SPECIFIED
- Pcb Contact Pattern
- STAGGERED
- Depth
- 12.5mm
- Parça Durumu
- Active
- Insertion Forcemax
- 3.336 N
- Contact Type
- Signal
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Withdrawl Forcemin
- 3.336 N
- Uzunluk
- 69.7mm
- Current Rating Amps
- 6.5A
- Sıra Sayısı
- 2
- Empty Shell
- NO
- Kontak Formu
- Stamped
- Montaj
- Through Hole
- Bodyshell Style
- PLUG
- ECCN Kodu
- EAR99
- Iec Conformance
- YES
