Volume pricing
- 1+ pcs$9.14
- 10+ pcs$8.62
- 100+ pcs$8.13
- 500+ pcs$7.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Number Of Pcb Rows
- 2
- Ambalaj
- Bulk
- Mixed Contacts
- NO
- Shell Size Connector Layout
- 3 DB B
- Mil Conformance
- NO
- Insulation Resistance
- 10000000000Ohm
- Connector Type
- Plug, Male Pins
- Çalışma Sıcaklığı
- -55°C~125°C
- Withdrawl Forcemin
- 3.336 N
- Current Rating Amps
- 7.5A
- Contact Type
- Signal
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kontak Formu
- Machined
- Özellikler
- Board Lock, Grounding Indents
- Empty Shell
- NO
- Sıra Sayısı
- 2
- Iec Conformance
- YES
- Montaj
- Through Hole
- Bodyshell Style
- RECEPTACLE
- Mating Contact Pitch
- 0.109 inch
- ECCN Kodu
- EAR99
- Material Flammability Rating
- UL94 V-0
- Body Breadth
- 0.508 inch
- Total Number Of Contacts
- 25
- Pozisyon Sayısı
- 25
- Contact Materials
- Copper Alloy
- Dielectric Withstanding Voltage
- 1000VAC V
- RoHS Durumu
- ROHS3 Compliant
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- Body Depth
- 0.583 inch
- Ul Flammability Code
- 94V-0
- Option
- GENERAL PURPOSE
- Connector Style
- D-Sub
- Parça Durumu
- Active
- Insertion Forcemax
- 3.336 N
- Housing Material
- PBT
- Contact Finish Mating
- NOT SPECIFIED
- Pcb Contact Pattern
- STAGGERED
- Shell Material Finish
- Steel
- HTS Kodu
- 8536.69.40.30
