Volume pricing
- 1+ pcs$9.62
- 10+ pcs$9.08
- 100+ pcs$8.56
- 500+ pcs$8.08
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Type
- Signal
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- HTS Kodu
- 8536.69.40.30
- Current Rating Amps
- 6.5A
- Withdrawl Forcemin
- 3.336 N
- Shell Material Finish
- Steel
- Empty Shell
- NO
- Sıra Sayısı
- 2
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Mating Information
- MULTIPLE MATING PARTS AVAILABLE
- Din Conformance
- YES
- Kontak Formu
- Stamped
- Fabrika Tedarik Süresi
- 7 Weeks
- Filter Feature
- NO
- Bodyshell Style
- PLUG
- Montaj Tipi
- Through Hole
- Shell Finish
- TIN
- Mating Contact Pitch
- 0.109 inch
- ECCN Kodu
- EAR99
- Montaj
- Through Hole
- Iec Conformance
- YES
- Terminal
- Solder
- Contact Resistance
- 10mOhm
- Total Number Of Contacts
- 25
- Pozisyon Sayısı
- 25
- Kurşunsuz Kodu
- yes
- Reference Standard
- UL
- Material Flammability Rating
- UL94 V-0
- Ambalaj
- Bulk
- Contact Materials
- Copper Alloy
- Number Of Pcb Rows
- 2
- Dielectric Withstanding Voltage
- 1000VAC V
- Mixed Contacts
- NO
- Ul Flammability Code
- 94V-0
- Flange Feature
- Mating Side, Female Screwlock (4-40)
- RoHS Durumu
- ROHS3 Compliant
- Connector Style
- D-Sub
- Connector Type
- Receptacle, Female Sockets
- Option
- GENERAL PURPOSE
- Shell Size Connector Layout
- 3 DB B
