Volume pricing
- 1+ pcs$9.38
- 10+ pcs$8.85
- 100+ pcs$8.35
- 500+ pcs$7.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Ambalaj
- Bulk
- Mixed Contacts
- NO
- Kılıf / Paket
- Metal
- Material
- Liquid Crystal Polymer, Polymer
- Connector Type
- Receptacle, Female Sockets
- Nominal Gerilim
- 32V
- Contact Design
- PREASSEM CONN
- Shell Size Connector Layout
- 2 DA A
- Mil Conformance
- NO
- Pitch
- 2.77mm
- Min. Çalışma Sıcaklığı
- -40°C
- Contact Type
- Signal
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Rating Amps
- 2A
- Uzunluk
- 39.1mm
- Empty Shell
- NO
- Sıra Sayısı
- 2
- Özellikler
- Feed Through
- Bodyshell Style
- PLUG
- ECCN Kodu
- EAR99
- Montaj
- Panel
- Iec Conformance
- YES
- Total Number Of Contacts
- 15
- Material Flammability Rating
- UL94 V-0
- Body Breadth
- 0.509 inch
- Contact Materials
- Copper Alloy
- Ul Flammability Code
- 94V-0
- Flange Feature
- Housing/Shell (Unthreaded)
- RoHS Durumu
- ROHS3 Compliant
- Wire Gauge Max
- 26 AWG
- Connector Style
- D-Sub
- Option
- GENERAL PURPOSE
- Orientation
- Right Angle
- Terminal Sayısı
- 15
- Maks. Çalışma Sıcaklığı
- 125°C
- Housing Material
- Polybutylene
- Contact Finish Mating
- NOT SPECIFIED
- Test Voltage
- 1kV
- Parça Durumu
- Active
- Depth
- 18.2mm
