Volume pricing
- 1+ pcs$49.24
- 10+ pcs$46.45
- 100+ pcs$43.82
- 500+ pcs$41.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Finish Mating
- NOT SPECIFIED
- Connector Type
- Receptacle, Female Sockets
- Reach Svhc
- No SVHC
- Dielectric Material
- Polycyclohexylenedimethylene Terephthalate (PCT)
- Max Supply Voltage
- 100V
- Kurşunsuz Kodu
- yes
- Connector Style
- D-Sub
- Parça Durumu
- Active
- Montaj
- Board Lock, PCB, Through Hole
- RoHS Durumu
- ROHS3 Compliant
- Housing Material
- Glass
- Empty Shell
- NO
- Terminal
- Solder
- Yükseklik
- 12.5mm
- Contact Resistance
- 10mOhm
- Flammability Rating
- UL94 V-0
- Kontak Formu
- Machined
- Uzunluk
- 53mm
- Depth
- 21.6mm
- Özellikler
- Board Lock, Filter, Mounting Brackets
- Akım Değeri
- 7.5A
- Working Voltage
- 100V
- Material Flammability Rating
- UL94 V-0
- Additional Feature
- PANEL MOUNTABLE
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Total Number Of Contacts
- 25
- Din Conformance
- NO
- Insulation Resistance
- 1GOhm
- Fabrika Tedarik Süresi
- 19 Weeks
- Çalışma Sıcaklığı
- -55°C~125°C
- Flange Feature
- Housing/Shell (4-40)
- Mil Conformance
- NO
- Ambalaj
- Bulk
- Gender
- Receptacle
- Contact Plating
- Gold
- Shell Material Finish
- Steel
- Orientation
- Right Angle
- Ul Flammability Code
- 94V-0
- Number Of Ports
- 1
- Sıra Sayısı
- 2
