Volume pricing
- 1+ pcs$6.90
- 10+ pcs$6.51
- 100+ pcs$6.14
- 500+ pcs$5.79
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Wire Gauge Max
- 26 AWG
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Montaj Tipi
- Panel Mount
- Rated Current Signal
- 2A
- Ambalaj
- Tray
- Genişlik
- 12.93mm
- Mating Contact Row Spacing
- 0.078 inch
- Akım Değeri
- 2A
- Bodyshell Style
- RECEPTACLE
- Mixed Contacts
- NO
- Option
- GENERAL PURPOSE
- Contact Gender
- Male
- Pitch
- 2.41mm
- Kurşunsuz Kodu
- yes
- Test Voltage
- 1kV
- Mil Conformance
- NO
- Uzunluk
- 69.8mm
- Flange Feature
- Housing/Shell (Unthreaded)
- Montaj
- Panel
- RoHS Durumu
- ROHS3 Compliant
- Total Number Of Contacts
- 62
- Pozisyon Sayısı
- 62
- Body Breadth
- 0.492 inch
- Insulation Resistance
- 5000000000Ohm
- Connector Style
- D-Sub, High Density
- Wire Gauge Min
- 24 AWG
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Çalışma Sıcaklığı
- -55°C~105°C
- Max Current Rating
- 2A
- Iec Conformance
- NO
- Fabrika Tedarik Süresi
- 10 Weeks
- Ul Flammability Code
- 94V-0
- Reliability
- COMMERCIAL
- Reach Svhc
- No SVHC
- Housing Material
- Steel
- ECCN Kodu
- EAR99
- Shell Size Connector Layout
- 4 DC C High Density
- Özellikler
- Grounding Indents
- Connector Type
- Plug for Male Contacts
- Yükseklik
- 12.55mm
