Volume pricing
- 1+ pcs$4.12
- 10+ pcs$3.88
- 100+ pcs$3.66
- 500+ pcs$3.46
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 12 Weeks
- Wire Size Max
- 24 AWG
- Wire Size Min
- 26 AWG
- Ul Flammability Code
- 94V-0
- Reliability
- COMMERCIAL
- Housing Material
- Steel
- Shell Size Connector Layout
- 3 DB B High Density
- ECCN Kodu
- EAR99
- Connector Type
- Plug for Male Contacts
- Özellikler
- Grounding Indents
- Contact Finish Mating
- NOT SPECIFIED
- Orientation
- Straight
- Sıra Sayısı
- 3
- Shell Material Finish
- Steel, Tin Plated
- Parça Durumu
- Active
- Contact Materials
- NOT SPECIFIED
- Contact Resistance
- 20mOhm
- Depth
- 15.91mm
- Terminal
- Crimp
- Note
- Contacts Not Included
- Filter Feature
- NO
- Din Conformance
- NO
- Reference Standard
- UL
- Plating
- Tin
- Empty Shell
- YES
- Contact Type
- Signal
- Montaj Tipi
- Panel Mount
- Rated Current Signal
- 2A
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Bodyshell Style
- RECEPTACLE
- Genişlik
- 12.93mm
- Mating Contact Row Spacing
- 0.078 inch
- Akım Değeri
- 2A
- Ambalaj
- Tray
- Option
- GENERAL PURPOSE
- Mixed Contacts
- NO
- Kurşunsuz Kodu
- yes
- Pitch
- 2.29mm
- Contact Gender
- Male
- Mil Conformance
- NO
