Volume pricing
- 1+ pcs$5.09
- 10+ pcs$4.81
- 100+ pcs$4.53
- 500+ pcs$4.28
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Housing Material
- Polybutylene
- Reach Svhc
- No SVHC
- Reliability
- COMMERCIAL
- Ul Flammability Code
- 94V-0
- Fabrika Tedarik Süresi
- 10 Weeks
- Orientation
- Right Angle
- Shell Material Finish
- Steel, Nickel Plated
- Sıra Sayısı
- 3
- Parça Durumu
- Active
- Contact Materials
- Copper Alloy
- Terminal Adımı
- 2.286mm
- Connector Type
- Plug, Male Pins
- Özellikler
- Board Lock, Grounding Indents
- Shell Size Connector Layout
- 1 DE E High Density
- ECCN Kodu
- EAR99
- Filter Feature
- NO
- Shell Material
- Steel
- Din Conformance
- NO
- Reference Standard
- UL
- Body Depth
- 0.646 inch
- Terminal
- Solder
- Contact Resistance
- 25mOhm
- Contact Plating
- Gold
- Empty Shell
- NO
- Contact Type
- Signal
- Plating
- Tin
- Contact Finish Thickness
- 30.0μin 0.76μm
- Pcb Contact Row Spacing
- 2.54 mm
- Akım Değeri
- 2A
- Mating Contact Row Spacing
- 0.078 inch
- Ambalaj
- Bulk
- Pcb Contact Pattern
- STAGGERED
- Number Of Pcb Rows
- 3
- Rated Current Signal
- 2A
- Montaj Tipi
- Through Hole, Right Angle
- Contact Finish
- Gold or Gold-Palladium
- Dielectric Material
- Polybutylene Terephthalate (PBT), Polyester, Glass Filled
- Mil Conformance
- NO
- Test Voltage
- 1kV
- Kurşunsuz Kodu
- yes
