Specifications
- Polarization Key
- POLARIZED HOUSING
- Akım Değeri
- 2A
- Mating Contact Row Spacing
- 0.1 inch
- Orientation
- Straight
- Uzunluk
- 55mm
- Contact Finish
- Gold
- Insertion Forcemax
- 1.5568 N
- Lead Pitch
- 2.54mm
- Dielectric Withstanding Voltage
- 1000VAC V
- RoHS Durumu
- ROHS3 Compliant
- Working Voltage
- 250V
- Mixed Contacts
- NO
- Insulation Resistance
- 1000000000000Ohm
- Reach Svhc
- No SVHC
- Reference Standard
- VDE,CSA
- Max Current Rating
- 2A
- Pitch
- 0.100 2.54mm
- Name Of Rows Loaded
- A,B,C
- Mil Conformance
- NO
- Min. Çalışma Sıcaklığı
- -65°C
- Lead Length
- 4mm
- Filter Feature
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e4
- Withdrawl Forcemin
- 1.5568 N
- Ul Flammability Code
- 94V-0
- Rated Current Signal
- 2A
- Material Insulation
- Thermoplastic, Glass Filled
- Number Of Pcb Rows
- 3
- Pozisyon Sayısı
- 48
- Contact Finish Thickness
- Flash
- Reliability
- COMMERCIAL
- Material Flammability Rating
- UL94 V-0
- Voltage Rated Dc
- 250V
- Style
- 2R
- Fabrika Tedarik Süresi
- 7 Weeks
- Parça Durumu
- Active
- Pcb Contact Pattern
- RECTANGULAR
- Kurşunsuz
- Lead Free
- Number Of Positions Loaded
- All
