Volume pricing
- 1+ pcs$3.47
- 10+ pcs$3.27
- 100+ pcs$3.09
- 500+ pcs$2.91
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Durability
- 400 Cycles
- Reference Standard
- UL
- Max Current Rating
- 2A
- RoHS Durumu
- ROHS3 Compliant
- Dielectric Withstanding Voltage
- 1000VAC V
- Mixed Contacts
- NO
- Insulation Resistance
- 10000000000Ohm
- Contact Finish
- Gold
- Uzunluk
- 54mm
- Polarization Key
- POLARIZED HOUSING
- Akım Değeri
- 2A
- Orientation
- Right Angle
- Mating Contact Row Spacing
- 0.1 inch
- Length Tail
- 3mm
- Number Of Pcb Rows
- 3
- Pozisyon Sayısı
- 48
- Contact Finish Thickness
- Flash
- Reliability
- COMMERCIAL
- Operating Temperature Min
- -55°C
- JESD-609 Kodu
- e4
- Ul Flammability Code
- 94V-0
- Material Insulation
- Thermoplastic, Glass Filled
- Rated Current Signal
- 2A
- Mil Conformance
- NO
- Name Of Rows Loaded
- A,B,C
- Filter Feature
- NO
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Özellikler
- Mounting Clips
- Pitch
- 0.100 2.54mm
- ECCN Kodu
- EAR99
- Number Of Positions Loaded
- All
- Sıra Sayısı
- 3
- Kurşunsuz
- Lead Free
- Contact Materials
- NOT SPECIFIED
- Pcb Contact Pattern
- RECTANGULAR
- Parça Durumu
- Active
- Material Flammability Rating
- UL94 V-0
- Style
- 2C
- Fabrika Tedarik Süresi
- 7 Weeks
- Seri
- DIN 41612
